Ergomat CNC Universal Lathe
Model TND 200

• Sturdy machine frame
• High performance machining
• User friendly
• 60º slant bed for optimal chip flow
• Servo driven 12-position turret
• Robust tailstock *
• Control FANUC 0i-TF
• All drives and servos FANUC
• Generous working space
• Cross slide and tailstock travelling on high-precision linear guides
• Servo-operated turret with 12 tool positions with direct tool clamping or VDI 30*
• Live tools VDI30*
• Programmable tailstock*
• Coolant system 6 bar (87 psi), option* 20 bar (290 psi)
• Moveable coolant tank for easy cleaning
• Chip conveyor* integrated in coolant tank
• Quick-change collet system
• Depth stop *
• Parts catcher with swivel arm and part gasket – parts can be removed while the machine is running*
• Parts conveyor*
• Chuck 210 mm (8“) or 254 mm* (10”)
• Interface for bar loading magazine*

Option*
